Cruxtec USB-C to DisplayPort V1.2 Cable 4K/60Hz
Cruxtec CD4K60H USB-C to DisplayPort V1.2 cables connect a compatible USB-C device with DisplayPort Alternate Mode to a DisplayPort display, supporting up to 4K@60Hz or 2K@144Hz.
- Model options: CD4K60H-01-BK (1m) and CD4K60H-02-BK (2m)
- Aluminum Alloy Housing
- Plug & Play; no additional software installation is required
- The device's USB-C output port must support DisplayPort Alternate Mode
Tech Specs
Tech Specs
Pin Plating: Gold
DisplayPort Version: DP1.2
Maximum Resolution: 4K@60Hz / 2K@144Hz
Connectors: USB-C Male to DisplayPort Male
Colour: Black
Cable Diameter (OD): 4.8mm
Sheath: PVC
Housing: Aluminum Alloy
Shield Type: Aluminum Foil Shield
DisplayPort Alternate Mode: Required
Plug & Play: Yes; no additional software required
Chipset: IF670
Cable Construction: (7/0.08T × 1P + AL + HM) × 4C + 7/0.08T × 1P + 7/0.08T × 4C + 7/0.2T × 2C + F + AB16/6/0.08AL; OD: 4.80mm; aluminum braided
Warranty
Warranty
1 Year
Plug & Play
No additional software installation is required. The USB-C port must support DisplayPort Alternate Mode.
DisplayPort V1.2
Supports resolutions up to 4K@60Hz and 2K@144Hz.
Gold-Plated Pins and Aluminum Alloy Housing
USB-C male to DisplayPort male.
Aluminum Foil Shielding
PVC sheath, 4.8mm OD and aluminum braided construction.
